Features & Benefits
Shock absorbers play a crucial role in maintaining a vehicle's stability, for instance, during the springtime when roads may display vulnerabilities caused by winter-induced potholes. Looking for a vehicle suspension upgrade, or shocks for other heavy duty trucks? Read on.
Does my Truck need a Suspension Upgrade?
Failure to replace worn-out shocks can result in drivers experiencing every bump, groove, or road instability, therefore increasing the risk of accidents, particularly for trucks.
The leading causes of shock failure often include weak weldings, cracked bushings, and excessive oil loss. Consequently, Monroe recommends inspecting and replacing vehicle shocks every 50,000 miles to ensure optimal performance and safety.
Here are some of the vehicles applications that Monroe shock absorbers are ideal for: 2017-2020 Autocar LLC. Xpert (Rear), 2012-2020 Western Star 4700SB (Rear), 2012-2017 Caterpillar CT660 (Rear), 2001-2017 Volvo VHD (Rear), 2010-2017 Mack TD700 (Rear), 2003-2022 Kenworth W900 (Rear), 2019-2020 International HV607 (Rear). Don't see your vehicle on the list? Call 1-800-245-7469 and we'll get you the right suspension upgrade.
Do Monroe Truck Shocks have a Warranty?
This product, tailored for Class 6-8 Vehicles, stands out as the first gas-charged, large-bore shock explicitly designed for air spring and taper leaf suspensions. Its nitrogen gas charge facilitates rapid responses crucial for heavy truck suspension systems, while the extra-large piston bore is engineered to certainly withstand the demands of high mileage and severe use.
The combination of the gas charge and large bore therefore ensures consistent control for demanding truck suspensions. Monroe stands behind the quality of its products, offering a limited lifetime warranty for the Magnum shock absorber.
This warranty covers qualifying Monroe products against defects and wear-out when used on private passenger cars and light trucks under normal operating conditions. With over a century of experience in delivering top-notch undercarriage and suspension parts for commercial fleet vehicles, Monroe is certainly a trusted name in the industry.
When in search of a vehicle suspension upgrade, opt for Monroe - a reliable choice with a legacy of excellence in the transportation sector.
FEATURES
- Designed for the following applications:
- 2017-2020 Autocar LLC. Xpert (Rear)
- 2008-2008 Autocar LLC. Xpeditor (Rear)
- 2009-2022 Autocar LLC. Xpeditor (Rear)
- 2009-2020 Autocar LLC. Xpeditor (Rear)
- 2012-2020 Western Star 4700SB (Rear)
- 2012-2020 Western Star 4700SF (Rear)
- 2012-2017 Caterpillar CT660 (Rear)
- 2001-2017 Volvo VHD (Rear)
- 2000-2018 Volvo VNL (Rear)
- 2010-2017 Mack TD700 (Rear)
- 2019-2021 Mack Pinnacle (Rear)
- 2003-2022 Kenworth W900 (Rear)
- 2013-2022 Kenworth T680 (Rear)
- 2014-2022 Kenworth T880 (Rear)
- 2019-2022 Kenworth W990 (Rear)
- 2019-2020 International HV607 (Rear)
- 2019-2020 International HV613 (Rear)
- 2019-2020 International HV513 (Rear)
- 2019-2020 International HV507 (Rear)
- Limited lifetime warranty
- Technician's most preferred shocks and struts brand
INCLUDES
- Shock Absorber
WARRANTY
- Limited Lifetime
SPECIFICATIONS
- Compressed Length: 15.172
- Compressed Length: 385.4
- Extended Length: 24.125
- Extended Length: 612.8
- Travel Length: 8.953
- Travel Length: 227.4
- Lower Mount Type: Loop Bushing and Sleeve Mount - 5/8"-16MM Sleeve ID X 3.9/16" Sleeve OAL
- Lower Mount Code: LS87
- Upper Mount Type: Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL
- Upper Mount Code: LS54
- Dust Shield Included: Yes
- Dust Shield Material : Metal
- Includes Bump Stop: No
- Internal Rebound Bumper: No
- Hydraulic Lockout: Yes
- Gas Charged: Yes
- Shock Absorber Rod End Measuring Point: Center of Loop
- Shock Absorber Body End Measuring Point: Center of Loop
- Parts Pack(s): P01471
- Part Description: Shock Absorber
