    Rancho RS7MT Shock RS77073

    Upgrade your Ford F-150 with Rancho RS7MT Shock RS77073, designed for precision on-road and off-road handling. These monotube shocks are perfect for extreme off-road use and larger tire packages, offering superior heat dissipation and durability. Engineered with advanced deflective disc valving and a dirt wiper sealing system, the RS7MT shocks provide a smooth, controlled ride, even in the most challenging conditions.

    Features of the RS77073:

    • Deflective Disc Valving: This technology offers digressive, linear, or progressive tuning based on application requirements, providing precision handling and enhanced performance on and off the road.
    • 14mm Hardened Chrome Piston Rod: Built to resist scuffs and corrosion, this durable rod ensures long-lasting performance, even in harsh driving conditions.
    • 2-Inch Monotube Body: The large body is filled with all-weather fluid, allowing for cooler operation and increased control. It can withstand extreme temperatures ranging from -40°F to 248°F.
    • High-Pressure Nitrogen Gas: This gas maintains constant pressure against the hydraulic oil, reducing aeration and preventing shock fade, ensuring consistent damping performance.
    • Integrated Dirt Wiper Sealing System: This system prevents moisture, dirt, and debris from entering the shock, protecting the internal components and prolonging the shock's life.
    • Internal Rebound Bumper: Reduces noise, vibration, and harshness, ensuring a smoother ride over various terrains.

    Benefits of the RS77073:

    • Precision Handling: The advanced deflective disc valving system offers customized tuning to match the specific needs of your Ford F-150, improving both on-road handling and off-road performance.
    • Extreme Durability: With a hardened chrome piston rod and double-welded loops at stress points, these shocks are built to handle the most challenging conditions and resist wear over time.
    • Smooth Ride: Features like the internal rebound bumper and PTFE-banded piston ensure a quieter, smoother ride by absorbing vibrations and providing responsive handling.
    • Improved Temperature Resistance: These shocks can handle extreme temperature fluctuations and maintain reliable performance regardless of the environment.
    • Greater Protection: The integrated dirt wiper sealing system and fluon-banded piston ensure that your shocks remain free of contaminants, extending their lifespan.

    Specifications of the RS77073:

    • Active or Passive Suspension: Passive
    • Adjustable Damping: No
    • Air Adjustable: No
    • Air Ride Suspension: No
    • Bearing Plate Included: No
    • Body Color: Black
    • Body Diameter (in): 1.97
    • Body Diameter (mm): 50
    • Boot Included: No
    • Coil Over Springs Included: No
    • Color: Black
    • Compressed Length (in): 18.02
    • Compressed Length (mm): 457.7
    • Cylinder Color: Black
    • Cylinder Material: Steel
    • Dust Shield Included: No
    • Extended Length (in): 27.9
    • Extended Length (mm): 708.7
    • Finish: Painted
    • Gas Charged: Yes
    • Grade Type: Performance
    • Grade Type: Progressive
    • Hydraulic Lockout: No
    • Includes Bump Stop: No
    • Internal Construction Type: Single Tube
    • Internal Rebound Bumper: Yes
    • Internal Rebound Spring: No
    • Lower Mount Code: LS39
    • Lower Mount Type: Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 1 5/8" Sleeve OAL
    • Mounting Hardware Included: No
    • New Or Remanufactured: New
    • Parts Pack(s): None
    • Rod Diameter (in): 0.5512
    • Rod Diameter (mm): 14
    • Shaft Material: Chromed
    • Shock Absorber Body End Measuring Point: Center of Loop
    • Shock Absorber Bore Size (in): 1.811
    • Shock Absorber Bore Size (mm): 46
    • Shock Absorber Rod End Measuring Point: Center of Loop
    • Spring Included: No
    • Spring Isolators Included: No
    • Spring Seat Included: No
    • Travel Length (in): 9.88
    • Travel Length (mm): 251
    • Type: Telescopic
    • Upper Mount Code: LS39
    • Upper Mount Type: Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 1 5/8" Sleeve OAL

    Upgrade your Ford F-150 with Rancho RS7MT Shock RS77073 and enjoy superior handling, durability, and ride comfort. Whether tackling challenging off-road trails or driving through varying road conditions, these shocks ensure optimal performance and longevity.

    For more information or to find the perfect fit for your Ford F-150, contact us at Shockwarehouse. We're here to help you optimize your vehicle's suspension system.

  • Fitments

    Vehicle
    Position
    Notes
    Year
    Ford F-150 King Ranch 4WD
    Rear
    without Off Road Package
    with Rear Raised Height 0 (in) to 1.5 (in)
    without Continuous Controlled Damping Suspension
    with Base or Medium Payload Packages
    Ford F-150 King Ranch 4WD
    Rear
    with Off Road Package
    with Rear Raised Height 1.5 (in)
    without Continuous Controlled Damping Suspension
    Ford F-150 King Ranch 4WD
    Rear
    with Heavy Duty Payload Package
    with Rear Raised Height 1.5 (in)
    without Continuous Controlled Damping Suspension
    Ford F-150 Lariat 4WD
    Rear
    without Off Road Package
    with Rear Raised Height 0 (in) to 1.5 (in)
    without Continuous Controlled Damping Suspension
    with Base or Medium Payload Packages
    Ford F-150 Lariat 4WD
    Rear
    with Off Road Package
    with Rear Raised Height 1.5 (in)
    without Continuous Controlled Damping Suspension
    Ford F-150 Lariat 4WD
    Rear
    with Heavy Duty Payload Package
    with Rear Raised Height 1.5 (in)
    without Continuous Controlled Damping Suspension
    Ford F-150 Lariat 4WD
    Rear
    without FX4 Package
    with Rear Raised Height 0
    with Base or Medium Payload Packages
    Ford F-150 Platinum 4WD
    Rear
    without Off Road Package
    with Rear Raised Height 0 (in) to 1.5 (in)
    without Continuous Controlled Damping Suspension
    with Base or Medium Payload Packages
    Ford F-150 Platinum 4WD
    Rear
    with Off Road Package
    with Rear Raised Height 1.5 (in)
    without Continuous Controlled Damping Suspension
    Ford F-150 Platinum 4WD
    Rear
    with Heavy Duty Payload Package
    with Rear Raised Height 1.5 (in)
    without Continuous Controlled Damping Suspension
    Ford F-150 Police Responder 4WD
    Rear
    without FX4 Package
    with Rear Raised Height 0
    with Base or Medium Payload Packages
    Ford F-150 SSV 4WD
    Rear
    without FX4 Package
    with Rear Raised Height 0
    with Base or Medium Payload Packages
    Ford F-150 STX 4WD
    Rear
    without FX4 Package
    with Rear Raised Height 0
    with Base or Medium Payload Packages
    Ford F-150 XL 4WD
    Rear
    without Off Road Package
    with Rear Raised Height 0 (in) to 1.5 (in)
    with Base or Medium Payload Packages
    Ford F-150 XL 4WD
    Rear
    with Heavy Duty Payload Package
    with Rear Raised Height 1.5 (in)
    Ford F-150 XL 4WD
    Rear
    with Off Road Package
    with Rear Raised Height 1.5 (in)
    Ford F-150 XL 4WD
    Rear
    without FX4 Package
    with Rear Raised Height 0
    with Base or Medium Payload Packages
    Ford F-150 XLT 4WD
    Rear
    without Off Road Package
    with Rear Raised Height 0 (in) to 1.5 (in)
    with Base or Medium Payload Packages
    Ford F-150 XLT 4WD
    Rear
    with Heavy Duty Payload Package
    with Rear Raised Height 1.5 (in)
    Ford F-150 XLT 4WD
    Rear
    with Off Road Package
    with Rear Raised Height 1.5 (in)
    Ford F-150 XLT 4WD
    Rear
    without FX4 Package
    with Rear Raised Height 0
    with Base or Medium Payload Packages
